谐波齿轮头数控回转轴（ID:103378）

设备部件 / 传动部件 / 谐波齿轮头数控回转轴

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	0000. Complete Assembly.SLDASM	912.31K
2	01. chuck backplate.SLDPRT	217.76K
3	01. inner pipe.SLDPRT	754.76K
4	02. fixed body.SLDPRT	145.33K
5	03. output face.SLDPRT	223.13K
6	04. Motor plate supporting rod.SLDPRT	105.23K
7	05. Motor Bracket.SLDPRT	188.44K
8	07. two-pieces 6061-t6 top housing.SLDPRT	312.34K
9	08. two-pieces 6061-t6 bottom housing.SLDPRT	145.27K
10	3jaw-chuck body.SLDPRT	257.78K
11	chuck-backplate assembly.SLDASM	156.51K
12	Harmonic Drive & Chuck.SLDASM	100.73K
13	harmonic drive 20-50.SLDASM	297.03K
14	SGMAS-01ACA21.SLDPRT	190.73K
15	simplified S3M 24T.SLDPRT	84.96K
16	simplified S3M 48T.SLDPRT	87.15K
17	socket head cap screw_am.sldprt	220.79K
18	socket set screw flat point_am.sldprt	165.09K
19	0000. Complete Assembly.STEP	4.78M
20	07. two-pieces 6061-t6 top housing.STEP	219.48K
21	08. two-pieces 6061-t6 bottom housing.STEP	105.89K
22	timing belt S3M.sldprt	76.42K
