PE4060颚式破碎机SW三维+CAD图纸==1361255=300S（ID:1340733）

机械设备 / 工程机械 / PE4060颚式破碎机SW三维+CAD图纸==1361255=300S

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17150171041681.zip	70.33M
2	K3125.01-07轴端挡圈.PDF	235.31K
3	PE4060-00-00颚式破碎机.PDF	310.00K
4	PE4060-01-00机架部分.PDF	331.79K
5	PE4060-01-01边护板.PDF	252.72K
6	PE4060-01-02固定颚板.PDF	287.69K
7	PE4060-01-03固定颚板螺栓.PDF	232.99K
8	PE4060-01-04油堵.PDF	234.71K
9	PE4060-01-05双头螺栓.PDF	230.33K
10	PE4060-01-06机架.PDF	360.63K
11	PE4060-01-07固定螺母.PDF	237.61K
12	PE4060-01-08颚破轴承盖（右）.PDF	253.57K
13	PE4060-01-09颚破轴承盖（左）.PDF	253.40K
14	PE4060-01-10边护板螺栓.PDF	230.41K
15	PE4060-01-11双头螺栓.PDF	230.37K
16	PE4060-01-12方螺母.PDF	230.33K
17	PE4060-02-00动颚部分.PDF	384.87K
18	PE4060-02-01机架密封套（内）.PDF	234.76K
19	PE4060-02-02机架密封盖.PDF	234.56K
20	PE4060-02-03飞轮.PDF	203.68K
21	PE4060-02-04机架端盖.PDF	184.17K
22	PE4060-02-05机架密封套（外）.PDF	235.00K
23	PE4060-02-06偏心轴.PDF	260.96K
24	PE4060-02-07动颚密封套.PDF	240.31K
25	PE4060-02-08动颚端盖.PDF	183.73K
26	PE4060-02-09调整垫.PDF	236.28K
27	PE4060-02-10动颚.PDF	227.17K
28	PE4060-02-11皮带轮.PDF	175.34K
29	PE4060-02-12动颚护板.PDF	232.64K
30	PE4060-02-13压块.PDF	179.30K
31	PE4060-02-14紧定衬套.PDF	181.99K
32	PE4060-02-16止退垫圈.PDF	235.28K
33	PE4060-02-17肘板垫.PDF	177.58K
34	PE4060-02-18活动颚板.PDF	221.34K
35	PE4060-02-19压条.PDF	229.38K
36	PE4060-02-20鄂破橡胶垫.PDF	231.89K
37	PE4060-03-00调整部分.PDF	235.01K
38	PE4060-03-01肘板.PDF	185.32K
39	PE4060-03-02挡块.PDF	228.65K
40	PE4060-03-03肘板垫.PDF	171.78K
41	PE4060-03-04调整座.PDF	183.86K
42	PE4060-03-05调整垫.PDF	177.00K
43	PE4060-03-06丝母.PDF	233.42K
44	PE4060-03-07丝杠.PDF	230.62K
45	PE4060-03-08垫片座.PDF	172.47K
46	PE4060-04-00拉紧弹簧部分.PDF	187.97K
47	PE4060-04-01拉杆.PDF	236.63K
48	PE4060-04-02弹簧座.PDF	237.35K
49	PE4060-04-03弹簧.PDF	251.05K
50	PE4060-05-01电机皮带轮.PDF	191.15K
51	PE4060-05-02电机导轨.PDF	177.65K
52	PE7510-20电机地脚螺栓.PDF	232.96K
53	K3125.01-07轴端挡圈.dwg	297.44K
54	PE4060-00-00颚式破碎机.dwg	477.31K
55	PE4060-01-00机架部分.dwg	568.03K
56	PE4060-01-01边护板.dwg	308.16K
57	PE4060-01-02固定颚板.dwg	348.31K
58	PE4060-01-03固定颚板螺栓.dwg	297.94K
59	PE4060-01-04油堵.dwg	301.19K
60	PE4060-01-05双头螺栓.dwg	296.72K
61	PE4060-01-06机架.dwg	410.59K
62	PE4060-01-07固定螺母.dwg	298.69K
63	PE4060-01-08颚破轴承盖（右）.dwg	326.88K
64	PE4060-01-09颚破轴承盖（左）.dwg	327.59K
65	PE4060-01-10边护板螺栓.dwg	297.69K
66	PE4060-01-11双头螺栓.dwg	296.97K
67	PE4060-01-12方螺母.dwg	296.72K
68	PE4060-02-00动颚部分.dwg	572.47K
69	PE4060-02-01机架密封套（内）.dwg	299.44K
70	PE4060-02-02机架密封盖.dwg	300.44K
71	PE4060-02-03飞轮.dwg	318.13K
72	PE4060-02-04机架端盖.dwg	309.41K
73	PE4060-02-05机架密封套（外）.dwg	298.94K
74	PE4060-02-06偏心轴.dwg	352.25K
75	PE4060-02-07动颚密封套.dwg	299.94K
76	PE4060-02-08动颚端盖.dwg	309.16K
77	PE4060-02-09调整垫.dwg	297.47K
78	PE4060-02-10动颚.dwg	403.34K
79	PE4060-02-11皮带轮.dwg	328.34K
80	PE4060-02-12动颚护板.dwg	301.19K
81	PE4060-02-13压块.dwg	303.94K
82	PE4060-02-14紧定衬套.dwg	303.19K
83	PE4060-02-16止退垫圈.dwg	301.44K
84	PE4060-02-17肘板垫.dwg	302.44K
85	PE4060-02-18活动颚板.dwg	362.22K
86	PE4060-02-19压条.dwg	297.44K
87	PE4060-02-20鄂破橡胶垫.dwg	297.69K
88	PE4060-03-00调整部分.dwg	402.38K
89	PE4060-03-01肘板.dwg	317.88K
90	PE4060-03-02挡块.dwg	296.97K
91	PE4060-03-03肘板垫.dwg	301.69K
92	PE4060-03-04调整座.dwg	323.38K
93	PE4060-03-05调整垫.dwg	304.69K
94	PE4060-03-06丝母.dwg	299.69K
95	PE4060-03-07丝杠.dwg	298.44K
96	PE4060-03-08垫片座.dwg	300.94K
97	PE4060-04-00拉紧弹簧部分.dwg	317.88K
98	PE4060-04-01拉杆.dwg	303.19K
99	PE4060-04-02弹簧座.dwg	297.69K
100	PE4060-04-03弹簧.dwg	317.38K
101	PE4060-05-01电机皮带轮.dwg	312.41K
102	PE4060-05-02电机导轨.dwg	317.88K
103	PE7510-20电机地脚螺栓.dwg	296.97K
104	DJ_Y系列IP44三相异步电动机B3_160-315_Y225M-6_30Kw.sldprt	1.04M
105	GB799-88地脚螺栓M24X1000.SLDPRT	93.45K
106	GB812-76圆螺母M150×2[GB／T812-1988].SLDPRT	135.53K
107	GB812-76圆螺母M180×3[GB／T812-1988].SLDPRT	150.10K
108	GB825-88吊环螺钉M12.SLDPRT	179.72K
109	GB_T288-94调心滚子轴承22238190x340x92.sldprt	359.45K
110	GB_T5780-2000螺栓M16×80.SLDPRT	115.81K
111	GB_T5781-2000螺栓M12x30.SLDPRT	155.74K
112	GB_T5781-2000螺栓M16×40.sldprt	116.65K
113	GB_T5781-2000螺栓M20×280.SLDPRT	113.43K
114	GB_T5783-2000螺栓M12X20.SLDPRT	104.81K
115	GB_T6170-2000螺母M16.SLDPRT	124.84K
116	GB_T6170-2000螺母M20.SLDPRT	122.53K
117	GB_T6170-2000螺母M24.SLDPRT	188.51K
118	GB_T6170-2000螺母M30.sldprt	135.70K
119	GB_T6172.1-2000螺母M24.SLDPRT	127.85K
120	GB_T70.1-2000内六方螺钉M12×30.SLDPRT	118.77K
121	GB_T70.1-2000内六方螺钉M16×40.SLDPRT	182.27K
122	GB_T70.1-2000内六方螺钉M16×65.SLDPRT	157.58K
123	GB_T93-1987弹簧垫圈12.SLDPRT	100.07K
124	GB_T93-1987弹簧垫圈16.sldprt	101.42K
125	GB_T93-1987弹簧垫圈20.SLDPRT	120.63K
126	GB_T93-1987弹簧垫圈24.sldprt	154.60K
127	GB_T95-2000平垫12.SLDPRT	72.82K
128	GB_T95-2000平垫24.SLDPRT	83.67K
129	GB_T95-2000平垫30.SLDPRT	53.92K
130	GB／T37-1988T形槽用螺栓M24×120.SLDPRT	118.21K
131	K3125.01-07轴端挡圈.SLDDRW	126.01K
132	K3125.01-07轴端挡圈.SLDPRT	78.25K
133	PE4060-00-00颚式破碎机.SLDASM	3.90M
134	PE4060-00-00颚式破碎机.SLDDRW	5.32M
135	PE4060-00-00颚式破碎机.STEP	19.41M
136	PE4060-01-00机架部分.SLDASM	1.05M
137	PE4060-01-00机架部分.SLDDRW	2.32M
138	PE4060-01-01边护板.SLDDRW	174.66K
139	PE4060-01-01边护板.SLDPRT	212.61K
140	PE4060-01-02固定颚板.SLDDRW	1.35M
141	PE4060-01-02固定颚板.SLDPRT	1.07M
142	PE4060-01-03固定颚板螺栓.SLDDRW	97.40K
143	PE4060-01-03固定颚板螺栓.SLDPRT	86.76K
144	PE4060-01-04油堵.SLDDRW	116.44K
145	PE4060-01-04油堵.SLDPRT	124.76K
146	PE4060-01-05双头螺栓.SLDDRW	83.86K
147	PE4060-01-05双头螺栓.SLDPRT	120.61K
148	PE4060-01-06机架.SLDDRW	2.44M
149	PE4060-01-06机架.SLDPRT	2.46M
150	PE4060-01-07固定螺母.SLDDRW	149.06K
151	PE4060-01-07固定螺母.SLDPRT	92.55K
152	PE4060-01-08颚破轴承盖（右）.SLDDRW	356.03K
153	PE4060-01-08颚破轴承盖（右）.SLDPRT	308.93K
154	PE4060-01-09颚破轴承盖（左）.SLDDRW	342.14K
155	PE4060-01-09颚破轴承盖（左）.SLDPRT	342.64K
156	PE4060-01-10边护板螺栓.SLDDRW	95.59K
157	PE4060-01-10边护板螺栓.sldprt	138.04K
158	PE4060-01-11双头螺栓.SLDDRW	82.21K
159	PE4060-01-11双头螺栓.SLDPRT	59.43K
160	PE4060-01-12方螺母.SLDDRW	98.42K
161	PE4060-01-12方螺母.SLDPRT	101.64K
162	PE4060-02-00动颚部分.SLDASM	1.83M
163	PE4060-02-00动颚部分.SLDDRW	4.94M
164	PE4060-02-01机架密封套（内）.SLDDRW	134.87K
165	PE4060-02-01机架密封套（内）.SLDPRT	160.98K
166	PE4060-02-02机架密封盖.SLDDRW	166.16K
167	PE4060-02-02机架密封盖.SLDPRT	103.18K
168	PE4060-02-03飞轮.SLDDRW	305.71K
169	PE4060-02-03飞轮.SLDPRT	232.54K
170	PE4060-02-04机架端盖.SLDDRW	209.24K
171	PE4060-02-04机架端盖.SLDPRT	143.01K
172	PE4060-02-05机架密封套（外）.SLDDRW	123.72K
173	PE4060-02-05机架密封套（外）.SLDPRT	99.59K
174	PE4060-02-06偏心轴.SLDDRW	704.05K
175	PE4060-02-06偏心轴.SLDPRT	371.30K
176	PE4060-02-07动颚密封套.SLDDRW	165.55K
177	PE4060-02-07动颚密封套.SLDPRT	150.61K
178	PE4060-02-08动颚端盖.SLDDRW	216.76K
179	PE4060-02-08动颚端盖.SLDPRT	137.85K
180	PE4060-02-09调整垫.SLDDRW	95.24K
181	PE4060-02-09调整垫.SLDPRT	79.43K
182	PE4060-02-10动颚.SLDDRW	1.81M
183	PE4060-02-10动颚.SLDPRT	979.64K
184	PE4060-02-11皮带轮.SLDDRW	459.11K
185	PE4060-02-11皮带轮.SLDPRT	299.97K
186	PE4060-02-12动颚护板.SLDDRW	129.28K
187	PE4060-02-12动颚护板.SLDPRT	90.94K
188	PE4060-02-13压块.SLDDRW	140.38K
189	PE4060-02-13压块.SLDPRT	110.75K
190	PE4060-02-14紧定衬套.SLDDRW	185.48K
191	PE4060-02-14紧定衬套.SLDPRT	118.16K
192	PE4060-02-15方头螺栓M24.sldprt	67.21K
193	PE4060-02-16止退垫圈.SLDDRW	120.04K
194	PE4060-02-16止退垫圈.SLDPRT	116.70K
195	PE4060-02-17肘板垫.SLDDRW	134.92K
196	PE4060-02-17肘板垫.SLDPRT	148.54K
197	PE4060-02-18活动颚板.SLDDRW	2.12M
198	PE4060-02-18活动颚板.SLDPRT	1.63M
199	PE4060-02-19压条.SLDDRW	84.81K
200	PE4060-02-19压条.SLDPRT	68.87K
201	PE4060-02-20鄂破橡胶垫.SLDDRW	86.85K
202	PE4060-02-20鄂破橡胶垫.SLDPRT	148.59K
203	PE4060-02-21挡油环.SLDPRT	105.09K
204	PE4060-03-00调整部分.SLDASM	418.89K
205	PE4060-03-00调整部分.SLDDRW	795.76K
206	PE4060-03-01肘板.SLDDRW	141.25K
207	PE4060-03-01肘板.SLDPRT	336.54K
208	PE4060-03-02挡块.SLDDRW	99.68K
209	PE4060-03-02挡块.SLDPRT	74.27K
210	PE4060-03-03肘板垫.SLDDRW	106.89K
211	PE4060-03-03肘板垫.SLDPRT	163.52K
212	PE4060-03-04调整座.SLDDRW	382.60K
213	PE4060-03-04调整座.SLDPRT	288.33K
214	PE4060-03-05调整垫.SLDDRW	116.82K
215	PE4060-03-05调整垫.SLDPRT	94.26K
216	PE4060-03-06丝母.SLDDRW	152.75K
217	PE4060-03-06丝母.SLDPRT	145.37K
218	PE4060-03-07丝杠.SLDDRW	108.11K
219	PE4060-03-07丝杠.SLDPRT	72.03K
220	PE4060-03-08垫片座.SLDDRW	99.73K
221	PE4060-03-08垫片座.SLDPRT	88.36K
222	PE4060-04-00拉紧弹簧部分.SLDASM	236.10K
223	PE4060-04-00拉紧弹簧部分.SLDDRW	287.39K
224	PE4060-04-01拉杆.SLDDRW	198.83K
225	PE4060-04-01拉杆.SLDPRT	80.04K
226	PE4060-04-02弹簧座.SLDDRW	146.79K
227	PE4060-04-02弹簧座.SLDPRT	97.73K
228	PE4060-04-03弹簧.SLDDRW	223.05K
229	PE4060-04-03弹簧.SLDPRT	286.17K
230	PE4060-05-01电机皮带轮.SLDDRW	274.88K
231	PE4060-05-01电机皮带轮.sldprt	201.12K
232	PE4060-05-02电机导轨.SLDDRW	175.64K
233	PE4060-05-02电机导轨.sldprt	209.11K
234	PE4060地基示意图.SLDPRT	109.91K
235	PE7510-20电机地脚螺栓.SLDDRW	105.45K
