带Dremel旋转刀具的CNCZ轴（ID:162301）

军用器械 / 冷兵器 / 带Dremel旋转刀具的CNCZ轴

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	ALL.SLDASM	15.51M
2	Back Plate.SLDPRT	53.17K
3	BALL BEARING 607 ZZ.SLDPRT	404.53K
4	Bearing 608zz.SLDPRT	313.90K
5	Bearing and Nut Housing.SLDPRT	95.05K
6	Bottom Plate.SLDPRT	47.28K
7	CNC Machine 2.JPG	364.36K
8	CNC Machine 3.JPG	360.89K
9	CNC Machine 4.JPG	358.35K
10	CNC Machine.JPG	390.01K
11	CNC Z axis.JPG	349.91K
12	CNC Z axis2.JPG	331.98K
13	CNC Z axis3.JPG	346.08K
14	Dremel Assembly.SLDASM	1.68M
15	Dremel Chord.SLDPRT	379.34K
16	Dremel Chuck Mount.SLDPRT	123.88K
17	Dremel Chuck.SLDPRT	158.17K
18	Dremel Left Half.SLDPRT	1.64M
19	Dremel mill Support.SLDPRT	69.04K
20	Dremel Motor Adjust.SLDPRT	114.73K
21	Dremel Right Half.SLDPRT	2.20M
22	Dremel Speed Lever.sldprt	147.50K
23	End Mill for Dremel.SLDPRT	320.71K
24	Frame Skeleton.SLDPRT	200.25K
25	Front Plate.SLDPRT	67.04K
26	M3 Socket Cap Screw 16mm Long.SLDPRT	937.50K
27	M3 Socket Cap Screw 30mm Long.SLDPRT	1012.58K
28	M3 Socket Cap Screw 35mm Long.SLDPRT	1.05M
29	M8 Nut.SLDPRT	383.61K
30	M8 Smooth Rod.SLDPRT	40.17K
31	M8 Threaded Rod For X.SLDPRT	3.45M
32	M8 Threaded Rod For Y.SLDPRT	4.42M
33	M8 Threaded Rod.SLDPRT	1.52M
34	M8 Washer.SLDPRT	69.34K
35	Motor Assembly.SLDASM	131.85K
36	NEMA 17 Stepper Motor.SLDPRT	312.89K
37	Pi奵e1.SLDPRT	230.32K
38	Printed Part as Joint.SLDPRT	99.14K
39	Side plate.SLDPRT	75.88K
40	Square tube clamp.SLDPRT	208.51K
41	X Carriage Angle Z.SLDPRT	65.13K
42	X Carriage Angle.SLDPRT	65.49K
43	X Carriage Mounting Plate Down.SLDPRT	80.83K
44	X Carriage Mounting Plate Top.SLDPRT	88.09K
45	X Carriage Mounting Plate.SLDPRT	77.00K
46	X Carriage Top Plate.SLDPRT	70.44K
47	X Carriage.SLDASM	2.19M
48	X Rail.SLDPRT	61.94K
49	Y Axis.SLDASM	2.33M
50	Y Carriage Plate.SLDPRT	75.50K
51	Y Carriage.SLDASM	2.31M
52	Y Rail 2.SLDPRT	64.13K
53	Y Rail.SLDPRT	63.31K
54	Z Axis.SLDASM	7.51M
55	Z Carriage Top Plate.SLDPRT	80.65K
56	Z Carriage.SLDASM	4.23M
57	Z Motor End Mount.SLDPRT	84.74K
58	Z Motor Mount.SLDPRT	86.84K
59	Z Nut Mount.SLDPRT	93.42K
