D1505-GSHP1000型回转式格栅除污机==642854=500_AutoCAD 2007_模型图纸下载

首页

图库

工程师

D1505-GSHP1000型回转式格栅除污机==642854=500（ID:1646954）

机械设备 / 非标机械 / D1505-GSHP1000型回转式格栅除污机==642854=500

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	1729675801326.zip	6.89M
2	微信截图_20240923065635.png	368.15K
3	微信截图_20240923065641.png	362.75K
4	微信截图_20240923065647.png	290.88K
5	微信截图_20240923065651.png	249.64K
6	-10支座.dwg	99.44K
7	-10支座.exb	85.50K
8	-10支座.PDF	26.46K
9	-11连接板.dwg	91.72K
10	-11连接板.exb	81.00K
11	-11连接板.PDF	14.30K
12	-12挡水板.dwg	93.97K
13	-12挡水板.exb	82.00K
14	-12挡水板.PDF	17.45K
15	-13压板.dwg	92.72K
16	-13压板.exb	81.50K
17	-13压板.PDF	16.41K
18	-14挡渣体.dwg	101.94K
19	-14挡渣体.exb	86.50K
20	-14挡渣体.PDF	26.23K
21	-1减速机座.dwg	110.16K
22	-1减速机座.exb	90.00K
23	-1减速机座.PDF	43.50K
24	-2挡板1.dwg	95.44K
25	-2挡板1.exb	83.00K
26	-2挡板1.PDF	16.34K
27	-3调节支座.dwg	101.69K
28	-3调节支座.exb	86.00K
29	-3调节支座.PDF	31.44K
30	-4压板.dwg	94.72K
31	-4压板.exb	83.00K
32	-4压板.PDF	14.50K
33	-5挡板.dwg	92.97K
34	-5挡板.exb	82.00K
35	-5挡板.PDF	17.44K
36	-6下部导轮.dwg	93.72K
37	-6下部导轮.exb	82.00K
38	-6下部导轮.PDF	17.75K
39	-7链轮罩.dwg	100.94K
40	-7链轮罩.exb	86.00K
41	-7链轮罩.PDF	24.74K
42	-8挡板.dwg	93.97K
43	-8挡板.exb	82.00K
44	-8挡板.PDF	15.69K
45	-9盖板.dwg	94.22K
46	-9盖板.exb	81.50K
47	-9盖板.PDF	15.79K
48	.1-1轴套.dwg	98.69K
49	.1-1轴套.exb	86.00K
50	.1-1轴套.PDF	25.82K
51	.1-2安全销.dwg	94.72K
52	.1-2安全销.exb	83.00K
53	.1-2安全销.PDF	17.15K
54	.1-3小链轮.dwg	96.19K
55	.1-3小链轮.exb	84.00K
56	.1-3小链轮.PDF	29.00K
57	.1-4挡板.dwg	90.97K
58	.1-4挡板.exb	80.50K
59	.1-4挡板.PDF	11.87K
60	.1传动装置.dwg	97.44K
61	.1传动装置.exb	84.50K
62	.1传动装置.PDF	36.65K
63	.2-1轴.dwg	94.47K
64	.2-1轴.exb	82.00K
65	.2-1轴.PDF	16.25K
66	.2-2轴承.dwg	91.72K
67	.2-2轴承.exb	81.00K
68	.2-2轴承.PDF	17.48K
69	.2-3小链轮.dwg	94.97K
70	.2-3小链轮.exb	82.50K
71	.2-3小链轮.PDF	23.75K
72	.2-4挡板.dwg	90.97K
73	.2-4挡板.exb	80.50K
74	.2-4挡板.PDF	13.21K
75	.2主传动涨紧装置.dwg	96.69K
76	.2主传动涨紧装置.exb	84.50K
77	.2主传动涨紧装置.PDF	64.71K
78	.3-1轴套.dwg	90.47K
79	.3-1轴套.exb	79.00K
80	.3-1轴套.PDF	14.27K
81	.3-2主传动大链轮.dwg	104.19K
82	.3-2主传动大链轮.exb	88.00K
83	.3-2主传动大链轮.PDF	35.31K
84	.3-3轴.dwg	104.69K
85	.3-3轴.exb	88.00K
86	.3-3轴.PDF	27.95K
87	.3-4转刷大链轮.dwg	97.44K
88	.3-4转刷大链轮.exb	84.00K
89	.3-4转刷大链轮.PDF	26.11K
90	.3-5主传动大链轮.dwg	97.69K
91	.3-5主传动大链轮.exb	83.50K
92	.3-5主传动大链轮.PDF	26.36K
93	.3-6连接盘.dwg	95.69K
94	.3-6连接盘.exb	82.00K
95	.3-6连接盘.PDF	18.27K
96	.3-7丝杆.dwg	91.47K
97	.3-7丝杆.exb	80.00K
98	.3-7丝杆.PDF	14.47K
99	.3-8垫板.dwg	98.69K
100	.3-8垫板.exb	84.50K
101	.3-8垫板.PDF	22.06K
102	.3-9锁母.dwg	90.72K
103	.3-9锁母.exb	79.50K
104	.3-9锁母.PDF	13.02K
105	.3主传动装置.dwg	115.16K
106	.3主传动装置.exb	96.50K
107	.3主传动装置.PDF	56.07K
108	.4-1支架.dwg	98.44K
109	.4-1支架.exb	85.00K
110	.4-1支架.PDF	32.00K
111	.4-2轴.dwg	95.44K
112	.4-2轴.exb	83.00K
113	.4-2轴.PDF	18.28K
114	.4-3小链轮.dwg	95.22K
115	.4-3小链轮.exb	83.50K
116	.4-3小链轮.PDF	25.37K
117	.4-4轴承.dwg	91.97K
118	.4-4轴承.exb	81.00K
119	.4-4轴承.PDF	18.48K
120	.4-5挡板.dwg	90.97K
121	.4-5挡板.exb	80.50K
122	.4-5挡板.PDF	12.36K
123	.4转刷涨紧装置.dwg	96.97K
124	.4转刷涨紧装置.exb	84.50K
125	.4转刷涨紧装置.PDF	68.51K
126	.5-1转刷小链轮.dwg	96.44K
127	.5-1转刷小链轮.exb	83.50K
128	.5-1转刷小链轮.PDF	24.99K
129	.5-2传动轴.dwg	98.69K
130	.5-2传动轴.exb	84.50K
131	.5-2传动轴.PDF	19.55K
132	.5-3卡箍.dwg	94.22K
133	.5-3卡箍.exb	81.00K
134	.5-3卡箍.PDF	15.38K
135	.5-4毛刷.dwg	98.44K
136	.5-4毛刷.exb	83.50K
137	.5-4毛刷.PDF	28.71K
138	.5转刷.dwg	102.19K
139	.5转刷.exb	87.50K
140	.5转刷.PDF	36.91K
141	.6-1轴套.dwg	90.47K
142	.6-1轴套.exb	80.00K
143	.6-1轴套.PDF	11.61K
144	.6-2导轮.dwg	95.94K
145	.6-2导轮.exb	83.50K
146	.6-2导轮.PDF	20.74K
147	.6-3传动轴.dwg	93.22K
148	.6-3传动轴.exb	82.00K
149	.6-3传动轴.PDF	16.45K
150	.6上部导轮组.dwg	101.19K
151	.6上部导轮组.exb	87.50K
152	.6上部导轮组.PDF	29.19K
153	.7-10连接盘.dwg	94.72K
154	.7-10连接盘.exb	82.00K
155	.7-10连接盘.PDF	17.77K
156	.7-11导轨3.dwg	102.44K
157	.7-11导轨3.exb	87.00K
158	.7-11导轨3.PDF	26.84K
159	.7-1连接架1.dwg	97.44K
160	.7-1连接架1.exb	85.00K
161	.7-1连接架1.PDF	24.26K
162	.7-2支架.dwg	92.47K
163	.7-2支架.exb	81.00K
164	.7-2支架.PDF	12.91K
165	.7-3导轨1.dwg	93.72K
166	.7-3导轨1.exb	82.00K
167	.7-3导轨1.PDF	15.52K
168	.7-4吊耳.dwg	90.97K
169	.7-4吊耳.exb	80.50K
170	.7-4吊耳.PDF	13.82K
171	.7-5侧板.dwg	137.09K
172	.7-5侧板.exb	107.50K
173	.7-5侧板.PDF	56.30K
174	.7-6连接架2.dwg	101.69K
175	.7-6连接架2.exb	87.00K
176	.7-6连接架2.PDF	28.35K
177	.7-7导轨2.dwg	96.69K
178	.7-7导轨2.exb	83.50K
179	.7-7导轨2.PDF	17.76K
180	.7-8角钢.dwg	95.69K
181	.7-8角钢.exb	83.00K
182	.7-8角钢.PDF	17.87K
183	.7-9垫块.dwg	90.47K
184	.7-9垫块.exb	80.00K
185	.7-9垫块.PDF	13.87K
186	.7机架.dwg	117.63K
187	.7机架.exb	98.50K
188	.7机架.PDF	60.39K
189	.8-1栅齿.dwg	105.94K
190	.8-1栅齿.exb	89.00K
191	.8-1栅齿.PDF	21.11K
192	.8-2挡板.dwg	92.97K
193	.8-2挡板.exb	81.50K
194	.8-2挡板.PDF	14.42K
195	.8-3链板.dwg	90.97K
196	.8-3链板.exb	80.50K
197	.8-3链板.PDF	13.23K
198	.8-4滚轮.dwg	92.72K
199	.8-4滚轮.exb	81.50K
200	.8-4滚轮.PDF	14.41K
201	.8-5套筒.dwg	95.44K
202	.8-5套筒.exb	83.50K
203	.8-5套筒.PDF	16.87K
204	.8-6挡板.dwg	90.47K
205	.8-6挡板.exb	80.00K
206	.8-6挡板.PDF	12.45K
207	.8-7栅齿轴.dwg	97.44K
208	.8-7栅齿轴.exb	84.50K
209	.8-7栅齿轴.PDF	17.94K
210	.8-8挡圈.dwg	90.72K
211	.8-8挡圈.exb	80.00K
212	.8-8挡圈.PDF	12.41K
213	.8栅网.dwg	113.66K
214	.8栅网.exb	95.00K
215	.8栅网.PDF	59.51K
216	GSHP1000型回转式格栅除污机总图.dwg	152.03K
217	GSHP1000型回转式格栅除污机总图.exb	121.50K
218	GSHP1000型回转式格栅除污机总图.PDF	129.05K
219	GSHP1000型回转式格栅除污机总图.png	21.75K
220	上部导轮组.png	15.75K
221	主传动装置.png	25.17K
222	传动装置.png	14.00K
223	减速机座.png	14.91K
224	技术参数.png	7.07K
225	机架.png	20.34K
226	栅网.png	16.58K
227	转刷.png	15.38K
228	转刷涨紧装置.png	24.67K
229	轴.png	11.58K
