卧式储罐（ID:1835423）

机械设备 / 化工设备 / 卧式储罐

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17378853887553.zip	6.46M
2	TANQUEDEARMAZENAMENTO.jpg	114.33K
3	BARRACOMROSCA.SLDPRT	66.18K
4	BORRACHADEVEDAÇÃO.SLDPRT	102.13K
5	CHAPAAPOIOBASE.SLDPRT	106.67K
6	CHAPAAPOIOCURVA.SLDPRT	81.65K
7	CHAPAAPOIODOQUADRO.SLDPRT	121.11K
8	CHAPAAPOIOVERTICAL.SLDPRT	56.35K
9	CHAPAAPOIOVERTICALCURTA.SLDPRT	43.21K
10	CHAPAXADREZDEPISO.SLDPRT	59.73K
11	CORPOCILÍNDRICO.SLDPRT	94.15K
12	CURVALONGA90GRAUS.SLDPRT	162.47K
13	DEGRAUDAESCADA.SLDPRT	51.05K
14	ESCADADEACESSO.SLDPRT	62.52K
15	EspelharFLANGE.SLDPRT	101.63K
16	FLANGE.SLDPRT	119.20K
17	LATERALDAESCADA.SLDPRT	63.31K
18	PERNAANGULARDOQUADRO.SLDPRT	49.83K
19	PERNARETADOQUADRO.SLDPRT	43.86K
20	QUADRODAESCADA.SLDPRT	157.50K
21	SAPATA.SLDPRT	59.74K
22	TAMPO.SLDPRT	137.08K
23	TANQUEDEÁGUA.SLDASM	338.85K
24	TUBO4POL.SCH.40.SLDPRT	151.59K
25	ARRUELADEPRESSÃOM20.SLDPRT	121.82K
26	ARRUELALISAM10.SLDPRT	57.82K
27	ARRUELALISAM20.SLDPRT	58.68K
28	ASMEB16.5FlangeDNØ4POL.Class600.SLDPRT	107.17K
29	BARRAROSCADAM16.SLDPRT	77.65K
30	PARAF.HEXAG.MÉTRICOM10.SLDPRT	231.05K
31	PORCASEXT.MÉTRICAM10.SLDPRT	119.93K
32	PORCASEXT.MÉTRICAM20.SLDPRT	126.91K
33	PRISIONEIROM20.SLDPRT	170.04K
34	VÁLVULAGLOBOasmeb16.34fl-600lbs.sldprt	811.53K
35	CORPODOTANQUE.SLDASM	574.58K
36	ESCADADEACESSO.SLDASM	167.27K
37	PASSARELADEACESSO.SLDASM	198.08K
38	SUPORTEDOTANQUE.SLDASM	172.82K
39	TANQUEDEARMAZENAMENTO.SLDASM	909.33K
40	TUBOCOMFLANGE.SLDASM	168.88K
