莲花-L3（EV）空气盒总成（ID:2638200）

机械设备 / 非标机械 / 莲花-L3（EV）空气盒总成

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17581014045426.zip	49.27M
2	CC5300210N_FRONT_DECK_ASSY.CATProduct	84.70K
3	CC5300210N_FRONT_DECK_ASSY_WELD_POINTS.CATPart	165.99K
4	CC5300211N_GUSSET_UPR_FRAME_EXT_LH.CATPart	1.61M
5	CC5300212N_GUSSET_UPR_FRAME_EXT_RH.CATPart	2.39M
6	CC5300215N_ASSY_PANEL_COWL_TOP_OTR_LHD.CATProduct	55.92K
7	CC5300216N_REINF_COWL_TOP_UPR_LHD.CATPart	1.93M
8	CC5300217N_REINF_WIPER_INR_LHD.CATPart	1.65M
9	CC5300218N_REINF_WIPER_OTR_LHD.CATPart	1.59M
10	CC5300220N_SUB_ASSY_PANEL_COWL_TOP_OTR_LHD.CATPart	24.79M
11	CC5300225N_ASSY_REINF_WIPER_MOTOR_LHD.CATPart	2.14M
12	CC5300230N_ASSY_PANEL_COWL_TOP_INR_LHD.CATProduct	110.10K
13	CC5300231N_DUCT_AIR_INTAKE.CATPart	2.36M
14	CC5300235N_ASSY_BRKT_HVAC_B_LHD.CATPart	1.14M
15	CC5300240N_ASSY_REINF_COWL_TOP_INR_LHD.CATProduct	31.75K
16	CC5300245N_SUB_ASSY_REINF_COWL_TOP_INR_LHD.CATPart	8.42M
17	CC5300250N_ASSY_REINF_STG_COL_BRKT_LHD.CATPart	1.08M
