37.靠墙户外电控柜（ID:279）

电力仪表 / 钣金箱体 / 37.靠墙户外电控柜

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	'GJL0001.008.053安装板固定板.SLDPRT	524.00K
2	88290001-495-底座挡板.SLDPRT	169.00K
3	88298000-2-机柜底座焊接.SLDASM	422.00K
4	882980005-锁杆导向件.SLDPRT	310.00K
5	CL204-1铰链.SLDPRT	1.02M
6	GJL0001.006.012柜体装配.SLDASM	1.18M
7	GJL0001.006.013顶盖焊接.SLDASM	172.00K
8	GJL0001.006.014柜体焊接.SLDASM	447.00K
9	GJL0001.006.016门板组件焊接.SLDASM	265.00K
10	GJL0001.008.033柜体.SLDPRT	933.50K
11	GJL0001.008.034门楣.SLDPRT	596.00K
12	GJL0001.008.035底板.SLDPRT	741.50K
13	GJL0001.008.036顶盖.SLDPRT	1.18M
14	GJL0001.008.037前盖板.SLDPRT	372.00K
15	GJL0001.008.038门板.SLDPRT	885.50K
16	GJL0001.008.039下锁杆.SLDPRT	496.50K
17	GJL0001.008.040上锁杆.SLDPRT	387.00K
18	GJL0001.008.043中间隔板.SLDPRT	325.00K
19	GJL0001.008.044上挡板.SLDPRT	1.78M
20	GJL0001.008.047内门板.SLDPRT	1.16M
21	GJL0001.008.054安装板竖固定板.SLDPRT	1.88M
22	GJL0001.008.060主开关安装板.SLDPRT	716.00K
23	GJL0001.008.061微断开关安装板.SLDPRT	1.08M
24	GJL0001.008.062变压器焊接托梁.SLDPRT	458.00K
25	GJL0001.008.063变压器托梁.SLDPRT	488.00K
26	GJL0001.008.064变压器封板.SLDPRT	494.00K
27	GJL0001.008.06有机玻璃卡板.SLDPRT	1.09M
28	GJL0001.008.08顶盖左封板.SLDPRT	1.02M
29	GJL0001.008.10右柜体.SLDPRT	813.00K
30	GJL0001.008.11柜体加强梁.SLDPRT	475.00K
31	GJL0001.008.12底座焊接板.SLDPRT	404.00K
32	GJL0001.008.13底座封板.SLDPRT	546.00K
33	GJL8.128.005门板装配体.SLDASM	365.00K
34	MS729-1.SLDPRT	336.00K
35	MS830手柄.SLDPRT	270.50K
36	MS830锁体.SLDPRT	329.50K
37	MS830锁杆.SLDPRT	1.33M
38	S2断路器.SLDPRT	204.00K
39	焊接螺柱M6X25.SLDPRT	206.50K
40	焊接螺母M12.SLDPRT	640.00K
41	门锁MS830.SLDASM	282.00K
42	齿轮.SLDPRT	381.00K
