B18-麦克纳姆轮AGV自动导引车（ID:313376）

机械设备 / 智能装置 / B18-麦克纳姆轮AGV自动导引车

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16613204109997.rar	20.02M
2	AGV.STEP	45.45M
3	3206 A-2RS11.sldasm	70.00K
4	AGV.sldasm	3.38M
5	Air piston rod.sldprt	90.50K
6	B1-RAG-06S RESSORTS A GAZ - TIGE DIAMETRE 6 - B1-RAG-06S-01625008-400.sldprt	79.00K
7	circlip for bores normal_din_Circlip DIN 472 - 62 x 2.sldprt	60.50K
8	circlip for shafts normal_din_Circlip DIN 471 - 10 x 1.sldprt	60.00K
9	circlip for shafts normal_din_Circlip DIN 471 - 30 x 1.5.sldprt	60.50K
10	circlip for shafts normal_din_Circlip DIN 471 - 32 x 1.5.sldprt	60.50K
11	circlip for shafts normal_din_Circlip DIN 471 - 6 x 0.7.sldprt	63.50K
12	die_spring_203-810.sldprt	715.50K
13	Hub cap.sldprt	84.00K
14	Igus Iglidur F 32x36.sldprt	56.50K
15	Main rod.sldprt	90.50K
16	Motor mount - mirror.sldprt	138.00K
17	Motor mount.sldprt	136.50K
18	Motor with gearbox 65_2_6355_f08-g03-e07.sldprt	181.50K
19	plain washer clevis pin grade a_din_Washer ISO 8738 - 14.sldprt	54.00K
20	plain washer grade a_din_Washer DIN 125 - A 8.4.sldprt	54.00K
21	plain washer small grade a_din_Washer DIN 433 - 10.5.sldprt	54.00K
22	Roller bushing.sldprt	54.00K
23	Roller plate (inner).sldprt	1.26M
24	Roller plate (outer).sldprt	2.89M
25	Roller shaft.sldprt	58.50K
26	Roller.sldprt	62.00K
27	Smalley 22mm spring.sldprt	84.50K
28	socket countersunk head screw_din_DIN 7991 - M5 x 20 --- 14.8N.sldprt	61.00K
29	socket countersunk head screw_din_DIN 7991 - M8 x 30 --- 21.8N.sldprt	60.50K
30	socket head cap screw 4762_din_ISO 4762 M8 x 20 --- 20N.sldprt	64.00K
31	Top plate_Domy榣na_Obrobiona_.sldprt	239.50K
32	W 61900-2RS1.sldasm	59.00K
33	Wheel hub.sldprt	105.00K
34	Wheel unit mount_Domy榣na_Obrobiona_.sldprt	780.00K
35	Wheel unit.sldasm	207.50K
36	_3206 A-2RS1_PART1.sldprt	97.00K
37	_3206 A-2RS1_PART2.sldprt	68.50K
38	_3206 A-2RS1_PART3_1.sldprt	53.50K
39	_3206 A-2RS1_PART4_1.sldprt	53.50K
40	_W 61900-2RS1_PART1.sldprt	89.50K
41	_W 61900-2RS1_PART2.sldprt	74.00K
42	_W 61900-2RS1_PART3.sldprt	53.50K
