太阳能电池板跟踪器（ID:327557）

人与自然 / 自然 / 太阳能电池板跟踪器

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16626128648426.zip	20.80M
2	6338K561_OIL-EMBEDDED FLANGED SLEEVE BEARING.SLDPRT	86.37K
3	6389K401_LIGHT DUTY DRY-RUNNING SLEEVE BEARING.SLDPRT	103.91K
4	6659K110_OIL-EMBEDDED FLANGED SLEEVE BEARING.SLDPRT	90.84K
5	90107A010_TYPE 316 STAINLESS STEEL FLAT WASHER.SLDPRT	69.55K
6	90441A114_ METRIC SLOTTED ROUND NUTS FOR TIGHT SPACES.SLDPRT	424.82K
7	90480A005_LOW-STRENGTH STEEL HEX NUT.SLDPRT	267.44K
8	90480A009_LOW-STRENGTH STEEL HEX NUT.SLDPRT	279.26K
9	90591A171_ZINC-PLATED STEEL HEX NUT.SLDPRT	361.88K
10	90710A030_TYPE 18-8 SS THIN HEX NUT - DIN 439B.SLDPRT	278.78K
11	91251A110_BLACK-OXIDE ALLOY STEEL SOCKET HEAD CAP SCREW.SLDPRT	680.30K
12	91290A224_BLACK-OXIDE CLASS 12.9 SOCKET HEAD CAP SCREW.SLDPRT	516.44K
13	91292A058_TYPE 18-8 SS SOCKET HEAD CAP SCREW.SLDPRT	661.05K
14	91864A024_BLACK-OXIDE ALLOY STEEL SOCKET HEAD CAP SCREW.SLDPRT	575.26K
15	92981A404_ALLOY STEEL SHOULDER SCREW.SLDPRT	775.97K
16	93791A407_BLACK OXIDE 18-8 SS FLAT-HEAD SCKT CAP SCREW.SLDPRT	362.27K
17	93791A408_BLACK OXIDE 18-8 SS FLAT-HEAD SCKT CAP SCREW.SLDPRT	412.25K
18	95610A330_NYLON PLASTIC WASHER.SLDPRT	60.82K
19	99607A274_SS FLARED-COLLAR KNURLED-HEAD THUMB SCREW.SLDPRT	1.91M
20	A03-PAYNE_CHRIS-base_plate.SLDPRT	223.29K
21	A03-PAYNE_CHRIS-cam_braket.SLDPRT	118.31K
22	A03-PAYNE_CHRIS-hinge_base.SLDPRT	131.98K
23	A03-PAYNE_CHRIS-hinge_bracket.SLDPRT	112.25K
24	A03-PAYNE_CHRIS-legs.SLDPRT	113.41K
25	A03-PAYNE_CHRIS-mounting_plate.SLDPRT	232.86K
26	A03-PAYNE_CHRIS-pole_insert.SLDPRT	90.12K
27	A03-PAYNE_CHRIS-servo_bracket.SLDPRT	115.74K
28	A03-PAYNE_CHRIS-ST_BASE.SLDASM	2.61M
29	A03-PAYNE_CHRIS-ST_PANEL_ASSEMBLY.SLDASM	861.22K
30	A03-PAYNE_CHRIS-ST_SYSTEM.SLDASM	5.26M
31	A03-PAYNE_CHRIS-upright.SLDPRT	69.16K
32	A03-PAYNE_CHRIS-VOLTIAC_221X257P_ANEL.SLDPRT	114.70K
33	A03-PAYNE_CHRIS-X_AXIS_SERVO.SLDASM	233.07K
34	A03-PAYNE_CHRIS-Y_axis-Drive_gear.SLDPRT	193.62K
35	A03-PAYNE_CHRIS-Y_axis-Servo_gear.SLDPRT	213.46K
36	A03-PAYNE_CHRIS-Y_AXIS_BASE.SLDASM	1.15M
37	A03-PAYNE_CHRIS-Y_axis_plate.SLDPRT	164.95K
38	A03-PAYNE_CHRIS-Y_AXIS_SERVO.SLDASM	284.72K
39	packed up iso.PNG	103.60K
40	Solar panel system back.PNG	90.58K
41	Solar panel system iso.PNG	59.23K
42	D-835WP LONG SERVO HORN.SLDPRT	82.47K
43	D-835WP SERVO.SLDASM	190.27K
44	D-835WP SERVO.SLDPRT	291.36K
45	~$D-835WP LONG SERVO HORN.SLDPRT	12B
46	~$D-835WP SERVO.SLDPRT	12B
