空调外机（ID:495688）

数码电器 / 家用电器 / 空调外机

©非原创

113

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16767308522807.zip	121.52M
2	Unit 24K.SLDPRT	52.16M
3	WhatsApp Image 2022-12-20 at 23.08.15.jpeg	33.78K
4	1. Outdoor fan.SLDPRT	2.49M
5	10. Front Panel.SLDPRT	1.24M
6	11. Motor Holder.SLDPRT	793.85K
7	12. Motor Holder Right Support.SLDPRT	276.19K
8	13. Motor Holder Left Support.SLDPRT	276.33K
9	14. Right side panel.SLDPRT	1.43M
10	15. Separation panel.SLDPRT	918.70K
11	16. Top cover.SLDPRT	151.42K
12	17. Valb plate.sldprt	531.67K
13	19. Compressor.SLDPRT	2.28M
14	20. Fan motor.SLDPRT	481.34K
15	21. Compressor Capacitor.SLDPRT	307.08K
16	22. Fan Capacitor.SLDPRT	202.10K
17	2404. Base plate.SLDPRT	1.14M
18	31. Cable lock.SLDPRT	88.04K
19	32. Terminal Board.SLDPRT	281.95K
20	37. Condenser hair pin tube(outer).SLDPRT	140.56K
21	38. Condenser hair pin tube(inner).SLDPRT	141.16K
22	39. Condenser Discharge tube.SLDPRT	216.86K
23	42. 2-way Distributor.SLDPRT	208.10K
24	43. 2-way to Hair Pin.SLDPRT	109.19K
25	44. Liquid service tube.SLDPRT	154.74K
26	45. Vapour service tube.SLDPRT	132.37K
27	46. Cross U.SLDPRT	146.33K
28	48. Gas Charging Tube.SLDPRT	72.17K
29	49. Expansion Device.SLDPRT	102.92K
30	5. Bottom Stud(left).SLDPRT	530.37K
31	5. Bottom Stud(Right).SLDPRT	816.36K
32	50. 3-way U.SLDPRT	285.69K
33	51. Return U R1.SLDPRT	162.90K
34	51. Return U R2.SLDPRT	167.98K
35	52. Y Distributor.SLDPRT	267.75K
36	59. Liquid service valve.SLDPRT	805.06K
37	6. Condenser Clamp(front side).SLDPRT	333.85K
38	60. Vapour service valve.SLDPRT	1.07M
39	7. Condenser Clamp(back side).SLDPRT	197.39K
40	8. Capacitor clamp.SLDPRT	102.89K
41	9. Electric plate.SLDPRT	12.51M
42	outdoor Unit.STEP	37.88M
