NAZD224 行星齿轮减速器（ID:713019）

设备部件 / 电机减速机 / NAZD224 行星齿轮减速器

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16936435363369.zip	16.11M
2	deepgrooveballbearingsgb_Rollingbearings6204GB276-94.prt	764.00K
3	deepgrooveballbearingsgb_Rollingbearings6206GB276-94.prt	808.00K
4	deepgrooveballbearingsgb_Rollingbearings6207GB276-94.prt	868.00K
5	deepgrooveballbearingsgb_Rollingbearings6216GB276-94.prt	1016.00K
6	eyeboltsgb_GB_FASTENER_SCREWS_FRSM16-N.prt	421.50K
7	hexagonheadbolts--productgradecgb_GB_FASTENER_BOLT_HHBCM10X45-N.prt	166.00K
8	hexagonheadbolts--productgradecgb_GB_FASTENER_BOLT_HHBCM10X55-N.prt	165.50K
9	hexagonheadbolts--productgradecgb_GB_FASTENER_BOLT_HHBCM6X30-N.prt	165.00K
10	hexagonheadbolts--productgradecgb_GB_FASTENER_BOLT_HHBCM6X45-N.prt	164.50K
11	hexnuts-stylenormal-gradesabgb_GB_HEXAGON_TYPE10M10X1.25-N.prt	179.50K
12	NAZD224-10毡圈.prt	96.50K
13	NAZD224-12斜面体.prt	752.00K
14	NAZD224-13低速轴.prt	382.00K
15	NAZD224-14Z30外齿轮.prt	708.00K
16	NAZD224-15轴套.prt	98.50K
17	NAZD224-16行星架.prt	516.00K
18	NAZD224-17小轴.prt	81.50K
19	NAZD224-18柱塞片.prt	203.50K
20	NAZD224-19内齿轮.prt	1.47M
21	NAZD224-1机座.prt	804.00K
22	NAZD224-20高速级大齿轮.prt	5.61M
23	NAZD224-21右支撑.prt	139.50K
24	NAZD224-22Z18外齿轮.prt	1.50M
25	NAZD224-23卡簧.prt	160.00K
26	NAZD224-24端盖.prt	346.00K
27	NAZD224-25毡圈.prt	96.50K
28	NAZD224-26挡盖.prt	154.50K
29	NAZD224-2通气阀.prt	912.00K
30	NAZD224-3外壳1.prt	1.94M
31	NAZD224-4外壳2.prt	1.04M
32	NAZD224-5紧定螺钉.prt	125.50K
33	NAZD224-6油塞.prt	147.00K
34	NAZD224-7小斜齿轮.prt	1.24M
35	NAZD224-8轴套.prt	98.50K
36	NAZD224-9轴承盖.prt	325.00K
37	NAZD224行星齿轮减速器.prt	187.50K
38	springlockwashers--normaltypegb_GB_FASTENER_WASHER_SW10.prt	116.00K
