3HD120干泵（ID:734852）

机械设备 / 非标机械 / 3HD120干泵

©非原创

平面图

3D视图

文件列表

#	文件名称	文件大小
1	16964081358459.zip	9.41M
2	20013589_A_3-Bolt_Stud_DIN939Fo__M12xL35_Steel8.8-zincblue.sldprt	19.71K
3	20076154_A_2-__X2_C18C_X0__Washer_Flat_M810.33x25.4x4.75t_SB_.sldprt	18.61K
4	20076267_A_3-Regulator_N25-100psigSmallSize.sldprt	169.84K
5	20103119_A_4-Bolt_Hexsocketheadcap_DIN912__M8xL16_Steel12.9-_zincblue.sldprt	22.98K
6	20103120_A_4-Bolt_Hexsocketheadcap_DIN912__M8xL20_Steel12.9-_zincblue.sldprt	22.59K
7	20103121_A_4-Bolt_Hexsocketheadcap_DIN912__M8xL25_Steel12.9-_zincblue.sldprt	22.13K
8	21101115_A_3-Nut_Hex_DIN934__M12_Steel-zincblue.sldprt	25.17K
9	22101106_A_2-__X2_C18C_X0__Washer_Flat_M815.6x8.3x1._6t.sldprt	18.63K
10	22101109_A_3-Washer_Flat_DIN125A__M12_Steel-zincblue.sldprt	19.59K
11	23194407_A_3-Centering_ManifoldExhaust_KF40_STN.sldprt	20.77K
12	23393301_B_1-Centering_WH700Adapter_LD1000P_Outer_NW63.sldprt	18.25K
13	36116120_A_4-Flange_WS501BlowerInlet_NW63_SS41C.sldprt	23.74K
14	43131240_A_3-Ring_RetainerManifoldExhaust_KF40.sldprt	19.40K
15	72138121_A_3-__X2_C18C_X0__StandoffSet_MainCable.sldprt	35.21K
16	72322426_B_1-GUARD_PUSH-PULLOPERATOR.sldprt	44.33K
17	72477545_A_3-SightGlass_SidePanel_69.8x39.7_Polycarbonate.sldprt	22.65K
18	7770026_A_2-Cap_End_NW40.sldprt	19.73K
19	7770039_A_3-__X2_C18C_X0__Nut_Hex_M5_SUS__X2_C0ACC6A9_X0_X__.sldprt	21.35K
20	7770041_A_3-Washer_EXTtoothlock_DIN6797A__M5_SUS.sldprt	41.83K
21	7770043_A_5-Bolt_HexsocketheadcapwithSpeciallowhead__BN1206___M6xL10_Steel10.9-Nikel.sldprt	21.40K
22	7770045_A_4-Bolt_Hexsocketheadcap_DIN912__M6xL10_SUS.sldprt	22.52K
23	7770047_A_3-Bolt_Flatcountersunkheadsocketcap_DIN7991__M6xL10__Steel10.9-NiP.sldprt	22.29K
24	7770049_A_3-Washer_Spring_DIN127B__M8_SUS.sldprt	20.97K
25	7770056_A_6-Bolt_Panhead___2Sems_M3xL8_Steel4.8-zincblue.sldprt	39.69K
26	7770097_A_4-Bolt_HexsocketheadcapwithSpeciallowhead__BN1206___M6xL16_Steel10.9-Nikel.sldprt	22.68K
27	7780054_A_4-QuickConnector_Nipple_Female__3_8NPT.sldprt	42.09K
28	7780055_A_3-QuickConnector_Coupler_Male__3_8NPT.sldprt	395.87K
29	7810123_A_3-O-Ring_ExhaustManifold_ID40.64x5.33t_NW40__S-Viton_Wh_ite_.sldprt	21.91K
30	7830002_B_3-Cover_Inlet__X2_03A6_X0_163x3t_GalvanizedSteelIron.sldprt	20.65K
31	7830005_A_2-Plug_FittingDoubleFERL_1_4.sldprt	26.80K
32	7843046_A_1-LEDBOARD_LD120L_140X140.sldprt	134.39K
33	7860078_A_3-Connector_BulkheadMale_1_4-NPT3_8_SUS316.sldprt	48.75K
34	7860088_A_2-Nut_RegulatorPanelSmallSize_Aluminium.sldprt	134.10K
35	7862030_A_2-Leveler_HD120_FJSN10-75.sldprt	26.22K
36	7862031_A_2-Caster_HD120_600_1200FrontRevolving_MISUMI.sldprt	91.78K
37	7862032_A_2-Caster_HD120_600_1200RearStationary_MISUMI.sldprt	56.91K
38	7862038_1_2_A_1-FRONTFRAMEHD120.sldprt	184.95K
39	7862108_D_1-Manifold_HD120_402mm-NW40_SUS304L.sldprt	32.32K
40	7862109_1_2_B_1-SUPPORT_SIDERIGHT_HD120_8Cell.sldprt	126.59K
41	7862110_1_2_A_2-SUPPORT_SIDELEFT_HD120_8Cell.sldprt	126.69K
42	7862111_B_3-Panel_HD120TopFront.sldprt	62.39K
43	7862112_1_2_A_3-Panel_HD120SideLeft.sldprt	30.53K
44	7862113_1_2_C_1-Panel_HD120SideRight.sldprt	30.75K
45	7862118_D_1-Base_HD120_3t_SPCC.sldprt	344.82K
46	7863007_A_1-KeypadAssembly_HD120.sldprt	1.12M
47	7863009_A_1-MainSwitch_ML1_40A_660Vac_Black_GE_MZ35029_.sldprt	163.17K
48	7863013_B_1-EMO_Head__ZB4-BS44_Telemecanique.sldprt	36.94K
49	7863500_D_1-Cable_PowerConnectorToMainSwitch_L_1150.sldprt	93.54K
50	7863620_HD120_A_1-Cable_CommunicationCable_L_1100.sldprt	104.24K
51	7864001_C_2-Plate_HD120MainCableAssy.sldprt	85.29K
52	7864004_1_2_A_3-Panel_HD120Rear.sldprt	142.08K
53	7864005_A_2-Connector_UnionBulkheadType_Tube1_4.sldprt	34.70K
54	7864007_1_2_B_1-Panel_HD120FrontElecBox.sldprt	86.06K
55	7864010_A_2-Panel_HD120TopRear.sldprt	24.67K
56	7864011_A_2-Screw_MaleSupportSkin_M10xL12-M10xDP20_S45C.sldprt	23.82K
57	8046012_A_2-O-Ring_ID72.39x5.33t_AS-568-336__Viton.sldprt	22.68K
58	Bracket_HD120SeismicKitLowerGround_A_2.sldprt	24.49K
59	Bracket_HD120SeismicKitUpper_A_2.sldprt	29.44K
60	HD120_Outline_A.pdf	572.19K
61	HD120_Outline_A.SLDASM	4.22M
62	N100022_A_2-Clamp_EndGearLock_HLC-40A.sldprt	35.68K
63	PH7860024_F_1-RotorHousing_HD120Cold_GC250.sldprt	331.13K
