无线蓝牙耳机及充电盒全结构3D图（ID:854353）

数码电器 / 数码产品 / 无线蓝牙耳机及充电盒全结构3D图

©原创

288

平面图

3D视图

文件列表

#	文件名称	文件大小
1	17031673967067.rar	24.20M
2	000_charge_box_assy_asm.igs	15.90M
3	000_charge_box_assy_asm.stp	10.92M
4	000_charge_box_assy.asm.1	1.22M
5	00_earphone-l_assy.asm.1	1.02M
6	00_earphone-r_assy.asm.1	1017.56K
7	01_pcba_earphone.asm.1	56.13K
8	02_pcba_charger_box.asm.1	69.30K
9	03_pcba_pin_box.asm.1	62.52K
10	1.prt.1	565.28K
11	2.prt.1	184.14K
12	3.prt.1	65.07K
13	battery_charger_box.prt.1	82.85K
14	battery_earphone.prt.1	1.04M
15	charger_box_master.prt.1	1.92M
16	charge_box_body.prt.1	501.55K
17	charge_box_cover_r.prt.1	5.34M
18	deco_topr_earphone.prt.1	120.60K
19	deco_top_earphone.prt.1	192.13K
20	earphone_master.prt.1	2.31M
21	earphone_right_ref.asm.1	997.74K
22	housing_btmr_earphone.prt.1	2.27M
23	housing_btm_earphone.prt.1	2.48M
24	housing_topr_earphone.prt.1	1.07M
25	housing_top_earphone.prt.1	1.61M
26	inner_bracket_charger_box.prt.1	501.01K
27	lr.asm.1	984.87K
28	m16x4-p.prt.1	433.62K
29	maginet_earphone.prt.1	42.40K
30	mesh_dirt.prt.1	985.05K
31	pcb_charger_usb.prt.1	124.30K
32	pcb_earphone.prt.1	135.55K
33	pcb_pin_box.prt.1	85.74K
34	pin_box.prt.1	81.00K
35	pin_earphone.prt.1	88.41K
36	speaker_earphone_d8.prt.1	122.20K
37	stopper.prt.1	1.13M
38	usb_micro_629105136821.asm.1	72.76K
